    Uncooled FPA Vox Body Thermal Detector With 2X Real Time Electronic Zoom

    Ask Lasest Price
    Brand Name : JOHO
    Model Number : JH513-B
    Certification : ISO9001
    Payment Terms : T/T
    Delivery Time : 5000PCS/Year
    • Product Details
    • Company Profile

    Uncooled FPA Vox Body Thermal Detector With 2X Real Time Electronic Zoom

    Uncooled Vox FPA Human Body Thermal Detector Pixel 384×288
    H513-B is a new medical innovation. It can diagnose diabetes, arthritis, breast cancer and other diseases only by scanning, and does not radiate harmful substances to human body. High precision, powerful function, professional analysis software, jh513-b reports the professional examination results of doctors. It has also been successfully integrated into a new generation of thermal texture mapping system for breast diagnosis, head and face, thyroid, chest and abdomen, back, lower extremity forelimb / lower extremity, left and right, pelvis diagnosis.

    Features


    2X real time electronic zoom
    Automatic shutter compensation
    Ultra low power consumption
    Ethernet Remote Transmission and control
    Professional and user-friendly analysis software

    TECHNICAL SPECIFICATIONS
    Detector
    Detector typeUncooled FPA VOx
    Response spectral7.5~13.5μm
    Pixel320×240 (optional 640×480)
    Pitch17μm×17μm
    Image Performance
    Lens28.6mm (F/1.2)
    FocusingMotorized
    NETD50mK@30ºC
    Frame rate25Hz/30Hz
    Image Presentation
    Palette10 (Medical, Grey, Iron, Iron 10, Gradient, Midyellow,
    Midgreen, Rainbow, Midgray, Inverted gray)
    Zoom2x digital zoom
    Measurement
    Temperature range0ºC~+60ºC (able to be cusomized)
    Alarming Temp. Range25ºC~45ºC(able to be cusomized)
    Temperature accuracy±0.5ºC
    Storage
    Storage mediumPC
    Image/ Video FormatBMP/IRM
    Ambient Parameters
    Operation temperature-20ºC~+60ºC
    Storage temperature-20ºC~+60ºC
    Interface
    Customized interfaceEthernet
    Physical Parameters
    Dimension125(L)×95(W) ×160(H)mm
    Weight1.2Kg
    ColorBlack
