    2-Axis Dual-Sensor Night Vision Airborne EO IR Tracking System With Small Size

    Ask Lasest Price
    Brand Name : JOHO
    Model Number : JHP320-B220
    Certification : ISO9001
    Price : negotiation
    Payment Terms : T/T, L/C,, Western Union, MoneyGram
    Supply Ability : 50Sets/Year
    Delivery Time : negotiation
    • Product Details
    • Company Profile

    2-Axis Dual-Sensor Night Vision Airborne EO IR Tracking System With Small Size

    2-axis Dual-sensor Night Vision Airborne EO/IR System


    JHP320-B220 dual-sensor gimbal is applicable on UAV, small aircraft, aerostat and other airborne platforms for target surveillance, tracking and positioning. The system is an optical-mechanical-electrical integration, configured with 80mm uncooled thermal camera, 30×continuous zoom HD 1080p day light camera.


    Features and Functions
    1) Azimuth and elevation 2-axis stabilized platform, integrated with high accuracy gyro and servo control system, to realize full coverage reconnaissance, support both day and night observation.
    2) Small size, light weight, and compact structure, strong carrier adaptability, low consumption, and high cost-effectiveness.
    3) Video tracking capability with manual locking and tracking;
    4) High accuracy calibration to ensure the alignment of thermal camera and daylight camera.
    5) Capable of data return such as working mode, azimuth angle, elevation angle,etc.

    Technical Specification
    THERMAL CAMERA
    Detector640*512 Uncooled FPA
    Spectral band8μm~14μm
    Pixel17mm x 17mm
    Focal length80mm
    DAY LIGHT CAMERA
    Detector1/2.8" CMOS
    Focal length4.3~129mm, 30x
    Resolution1920×1080
    SERVO
    Stabilization accuracy≤0.5mrad(1σ)
    Turret direction rangeAzimuth:360° continuous; Elevation:+20°~-90° (Customizable)
    TURRET MAXIMUM ANGLE SPEED
    Azimuth≥30°/s
    Pitch≥30°/s
    INTERFACE
    Video OutHDMI
    CommunicationRS232
    ENVIRONMENTAL
    Operating temperature range-20℃ ~ +50℃
    Storage temperature range-30℃ ~ +60℃
    Tracking
    Tracking speed≥2.5FOV/S
    Min tracking contrast ratio5%
    Dynamic tracking accuracysuperior to 1mrad
    POWER
    Power SupplyDC 12V
    Power Consumption≤120W (steady); ≤360W(peak)
    PHYSICAL
    Dimension Turret≤ Φ240× 350mm
    Turret Weight≤ 10kg
    ColorCustomizable
    Performance (Theoretic Value under Johnson DRI)
    Vehicle (2.3×2.3m)Human (1.7×0.5m)
    Detection5400m1100m
    Recognition1800m400m
    Identification900m200m
