    High Precision Stabilized Electro Optical UAV Searching System

    Ask Lasest Price
    Brand Name : JOHO
    Model Number : D220
    Certification : ISO9001:2000
    Price : negotiation
    Payment Terms : T/T, L/C,
    Supply Ability : 100Sets/Year
    Delivery Time : 2-3months after received payment
    • Product Details
    • Company Profile

    High Precision Stabilized Electro Optical UAV Searching System

    High Precision Stabilized Electro Optical UAV Searching System


    D220UAV Gyro Stabilized Electro Optical IR Monitoring Targeting Payload System is designed to be carried bymedium size UAV, and integrated daylight camera, IR camera and stabilized servo platform, total weight is less 6kg. This payload system can be exploring, searching, identifying and even tracking the subject and live date transmission.


    Features

    360 degree continuous view

    Gyro stabilization better than180u rad

    High precision stabilized image independent of platform maneuvers and vibrations

    Autonomous R&D FPA IR detector and advanced precision imaging system, high quality image

    Advanced algorithm of object identification tracking, high auto tracking accuracy


    Applications

    UAV/ Helicopter for Search and Rescue


    Specification

    Camera

    Image resolution

    2400 megapixel

    Video resolution

    1920×1080

    Recognition Range

    3mm×10mm linear target in the range of 55m.

    Stabilized Accuracy

    ≤0.2mrad

    Movement Range

    Azimuth

    360° ×n continuous

    Pitch

    +20~-110°(horizontal forward is 0°)

    Record capability

    Images

    32G, capable of storage more than 2000pcs image

    Video

    32G, capable of storage 1080P HD more than 4h

    Physical

    Volume

    φ220×350mm

    Weight

    ≤6Kg


    Company Profile
    Wuhan JOHO Technology Co., Ltd founded in 2009, is a high-technology company based on infrared thermal imaging technology. Joho has built a complete infrared industrial chain from the bottom up: from core component to comprehensive electro optical infrared surveillance and tracking system.We have two R & D base in Hubei Zhongxiang and Wuhan City, well-known institutions of higher learning and research institutions at home and abroad.

    Customer Distribution

    Service Process

    Products
    Our products includes thermal security cameras, electro-optics/infrared search and track system (EO/IR search and track system) and EO surveillance system, surveillance radar, laser range finder, fiber optical gyro, special power sources (thermal battery and silver-zinc battery Ag-zn battery) and OEM solutions,Personalized products and services to provide customers with a significant advantage. Due to the high quality of our products and reliable performance, Joho products are widely used in different applications, security and surveillance, law enforcement, maritime patrol, fishery administration, surveying and mapping and so on.
