    20m~2km Long Range Surveillance System For Fixed UAV And Helicopter

    Ask Lasest Price
    Brand Name : JOHO
    Model Number : JHS640-240P4
    Certification : ISO9001:2000
    Supply Ability : 50 Sets/Year
    Delivery Time : Two months
    • Product Details
    • Company Profile

    20m~2km Long Range Surveillance System For Fixed UAV And Helicopter

    20m~2km Long Range Surveillance System For Fixed-UAV And Helicopter


    Applications
    It is used for fixed-UAV and helicopter observation own soldiers formation, search and rescue, recognition and tracking in forest and high grass.

    Functions

    1. Recognize 2km target, positioning, tracking ranging
    2. Output and process image and video in real time (include multi-spectral)
    3. Detect and recognize camouflage person by combined graphic of multi-spectral camera, infrared thermal camera and day light camera, show the target in pseudo-color
    4. Switch different video types, such as: day light and IR mode, multi-spectral and day light mode
    5. Support video image stabilization and two-axis PTZ
    6. Calculate GPS and coordinate of gimbal

    Technical Specifications

    JHS640-240P4 Multi-sensor UAV Gimbal
    Thermal Camera
    DetectorUncooled FPAPixel640×512
    Spectral band8μm~12μmFocal length75mm
    NETD≤50mK@25ºCRecognition distance1km
    ( person:1.8×0.5m)
    Day Light Camera
    DetectorCMOSFocal length20x optical zoom
    PixelHD1920×1080FOV55.4°~ 2.9°
    Laser Range Finder
    Wavelength1.55μmAccuracy≤ ± 5m
    Range20m~2km (visibility 10km, 3m*3m target)
    Multi-spectral Camera
    Wave length500nm-800nmPixel1280x1024
    Frame rate50HzRecognition distance500m
    ( person:1.8×0.5m)
    System Parameter
    Azimuth360°continuousElevation-110°~+20°
    Stabilization accuracy0.5mrad (1σ)CommunicationRS422
    Power supplyDC 9-36VPower consumption60W
    DimensionΦ240× 300mmWeight7kg

    20m~2km Long Range Surveillance System For Fixed UAV And Helicopter20m~2km Long Range Surveillance System For Fixed UAV And Helicopter

    Company Profile
    Wuhan JOHO Technology Co., Ltd founded in 2009, is a high-technology company based on infrared thermal imaging technology. Joho has built a complete infrared industrial chain from the bottom up: from core component to comprehensive electro optical infrared surveillance and tracking system.We have two R & D base in Hubei Zhongxiang and Wuhan City, well-known institutions of higher learning and research institutions at home and abroad.

    Customer Distribution

    Service Process

    Products
    Our products includes thermal security cameras, electro-optics/infrared search and track system (EO/IR search and track system) and EO surveillance system, surveillance radar, laser range finder, fiber optical gyro, special power sources (thermal battery and silver-zinc battery Ag-zn battery) and OEM solutions,Personalized products and services to provide customers with a significant advantage. Due to the high quality of our products and reliable performance, Joho products are widely used in different applications, security and surveillance, law enforcement, maritime patrol, fishery administration, surveying and mapping and so on.
