    17μM Uncooled FPA EO IR Tracking Gimbal With Thermal Camera And Day Light Camera

    17μM Uncooled FPA EO IR Tracking Gimbal With Thermal Camera And Day Light Camera


    JH601-25 dual-sensor gimbal is applicable on small vehicles for target surveillance and tracking at day and night. The system is an optical-mechanical-electrical integration, equipped with a LWIR uncooled thermal camera and a HD 1080p daylight camera, capable of output video /image in real-time, which is widely deployed in military field, public security and other civilian fields.


    Main Functions

    1) Azimuth and elevation 2-axis stabilized platform, integrated with high accuracy gyro and servo control system, to realize full coverage reconnaissance, support both day and night observation.

    2) Small size, light weight, and compact structure, strong carrier adaptability, low consumption, and high cost-effectiveness.

    3) Object tracking function;

    4) High accuracy calibration to ensure the alignment of thermal camera and daylight camera.

    5) Capable of data return such as working mode, azimuth angle, elevation angle, etc.


    Thermal Camera

    Detector640×512 Uncooled FPA
    Pixel size17μm
    Spectral band8um~14μm
    Focal length25mm (athermalization)
    FOV25°×20°
    NETD≤50mK(F/1)
    E-zoom2×, 4×
    Video interfacePAL analog video
    Day Light Camera
    Detector1/4 type Super HAD CCD
    ResolutionApprox 800000 pixels
    Digital zoom12× (312× with optical zoom)
    Focal length3.5mm~91mm (26× optical zoom)
    Video interfacePAL analog video
    System Parameters
    Stabilized platform2-axis gyro stabilized
    Stabilization accuracy≤1mrad(1σ)
    Angular accuracy±0.1°(1σ)
    Azimuth Range360º continuous
    Elevation Range-20°~+90°
    Azimuth swing speed1~60°/s (adjustable)
    Elevation swing speed1~100°/s (adjustable)
    Power supplyDC24V
    CommunicationRS485 (Pelco D)
    External interfaceSDI video
    Physical parameters
    Power consumption≤50W (stable), ≤120W (peak)
    Dimension≤Φ240mm×365mm
    ColorWhite gray
    Weight10kg
    Environmental Parameters
    Working temperature﹣40℃~﹢60℃
    Storage temperature﹣45℃~﹢70℃
    Vibration test10-35Hz, 35-160Hz, 0.5mm displacement, 25m/s2
    ProtectionIP66

    Company Profile

    Wuhan JOHO Technology Co., Ltd founded in 2009, is a high-technology company based on infrared thermal imaging technology. Joho has built a complete infrared industrial chain from the bottom up: from core component to comprehensive electro optical infrared surveillance and tracking system.We have two R & D base in Hubei Zhongxiang and Wuhan City, well-known institutions of higher learning and research institutions at home and abroad.

    Customer Distribution

    Service Process

    Products
    Our products includes thermal security cameras, electro-optics/infrared search and track system (EO/IR search and track system) and EO surveillance system, surveillance radar, laser range finder, fiber optical gyro, special power sources (thermal battery and silver-zinc battery Ag-zn battery) and OEM solutions,Personalized products and services to provide customers with a significant advantage. Due to the high quality of our products and reliable performance, Joho products are widely used in different applications, security and surveillance, law enforcement, maritime patrol, fishery administration, surveying and mapping and so on.
