Brand Name : | JOHO |
Model Number : | JH640-600/137/22 |
Certification : | CE; ISO9001;2000 |
Price : | negotiation |
Delivery Time : | negotiation |
JH640-600/137/22 is especially designed for long range
surveillance. Multiple field of view optics 600/137/22mm, it
achieves the super long mission of fast situational awareness and
target reorganization with the wonderful wide, medium and narrow
Field of view in one system. It is definitely a very good choice
for ground, coast and air defense EO system integrator.
Application
Range performace
Target | medium vehicle | human |
Detection range | ≥15km | ≥10 km |
Recognition range | ≥10 km | ≥5 km |
Technical Data
Detector | |
Detector materials | Cooled FPA HgCdTe |
Pixels | 640×512 |
Spectral range | 3.7~4.8μ m |
NETD | ≤ 15 mK (F#4) |
Cooling | ≤ 8Min, Stirling |
Optics | |
Lens | 600mm/137mm/22mm (F#4) |
FOV | WFOV: 24.6° × 19.8°/MFOV: 4° × 3.2°/NFOV: 0.92° × 0.73° |
Image presentation | |
Video output | Analog PAL/NTSC; digital Cameralink |
Frame frequency | 25Hz, 50Hz (100Hz, 200Hz optional) |
Brightness & contrast | Auto/Manual |
Polarity | B& W, B& W inverse |
Interfaces | |
Command and control | RS232/ RS422 alternative |
Interface | Optional: Cameralink |
Video output | RCA/BNC alternative |
Power System | |
Power supply | 110/ 220VAC adapter |
Environmental Parameters | |
Operating temperature | -40° C to +60° C |
Storage temperature | -40° C to +60° C |
Physical Characteristics | |
Weight | 8.1kg (without housing) |
