    Standard Interface 384×288 Uncooled Infrared LWIR Thermal Imaging Core

    Ask Lasest Price
    Brand Name : JOHO
    Model Number : UWA384CX-H09-F
    Certification : ISO9001:2000
    Price : negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 100Sets/Year
    Delivery Time : negotiable
    • Product Details
    • Company Profile

    Standard Interface 384×288 Uncooled Infrared LWIR Thermal Imaging Core

    Standard Interface 384×288 Uncooled Infrared LWIR Thermal Imaging Core

    Features

    • Suit long-range, multi-task search and observation
    • High sensitivity and high resolution
    • Standard interface , easy to integrate
    • Entire enclosure shell protection and compact design

    Technical Specification

    ModelUWA384CX-H09-F
    TypeVOx Uncooled Infrared LWIR
    Array format384×288, 25μm
    Spectral response8~14μm
    Power consumption≤1.7W@25℃
    Power supplyDC 6.5V~13V
    Time to image≤20s
    Operating temperature range-40℃~+60℃
    Storage temperature rage-55℃~+70℃
    NETD (@1/f. 25Hz)40mK
    Focus motor driverPWM adjustment
    Video output2 channel Analog video output, PAL formats
    Communication interfaceRS422
    Main control function

    Manual background calibration, Manual shutter calibration, Polarity setting, 1×~2× continuous zooming, Cross cursor display, Cross cursor position adjustment, Gain adjustment, Brightness adjustment,
    Digital Details Enhancement (DDE), Motorized focusing, Reticle display settings, System parameter reset

    Five type reticleStandard Interface 384×288 Uncooled Infrared LWIR Thermal Imaging Core
    Size46mm×48.9mm×42mm
    Weight≤90g


    Standard Interface 384×288 Uncooled Infrared LWIR Thermal Imaging CoreStandard Interface 384×288 Uncooled Infrared LWIR Thermal Imaging Core
    Company Profile

    Wuhan JOHO Technology Co., Ltd founded in 2009, is a high-technology company based on infrared thermal imaging technology. Joho has built a complete infrared industrial chain from the bottom up: from core component to comprehensive electro optical infrared surveillance and tracking system.We have two R & D base in Hubei Zhongxiang and Wuhan City, well-known institutions of higher learning and research institutions at home and abroad.





    Customer Distribution

    Service Process

    Products

    Our products includes thermal security cameras, electro-optics/infrared search and track system (EO/IR search and track system) and EO surveillance system, surveillance radar, laser range finder, fiber optical gyro, special power sources (thermal battery and silver-zinc battery Ag-zn battery) and OEM solutions,Personalized products and services to provide customers with a significant advantage. Due to the high quality of our products and reliable performance, Joho products are widely used in different applications, security and surveillance, law enforcement, maritime patrol, fishery administration, surveying and mapping and so on.
