    Infrared Night Vision Laser Range Finder Military Rangefinder

    Ask Lasest Price
    Brand Name : JOHO
    Model Number : JH18
    Certification : GJB
    Price : negotiation
    Payment Terms : T/T, L/C
    Supply Ability : 100Sets/Year
    Delivery Time : 2months after received payment
    • Product Details
    • Company Profile

    Infrared Night Vision Laser Range Finder Military Rangefinder

    Infrared Night Vision Laser Range Finder Military Rangefinder


    18km Laser Range Finder

    18km LRF


    Applications:


    Portable EO Surveillance System


    Features:

    1. Long range up to 18km
    2. Flexibility of use as alone device or working with thermal camera or night vision
    3. Lightweight

    Specifications:


    Measurement characteristics

    Measurement Range

    300m~18000m (tank:2.3mx2.3m)

    Range accuracy

    +/-5m

    Proper Probability

    ≥98%

    Repetition rate

    3Hz, working 1min, have a rest 1min

    Transmitter / Receiver

    Wavelength

    1.064μm

    Beam divergence

    ≤1.2mrad

    Interface requirements


    Communication Interface

    RS422

    Power supply

    24V-30V DC

    Environmental specification

    Operating Temperature

    -40℃~+55℃

    Storage Temperature

    -55℃~+70℃

    Relative humidity

    95±3% at 35℃

    Vibration

    Frequency range: 5Hz~200Hz~5Hz,

    Uniform accelerated sine vibration. Acceleration:1.5g.

    Direction: X, Y, Z Each direction for 12min

    Shock

    Acceleration: 30g

    Duration time: 11ms±2ms

    Direction: X, Y, Z

    Times: 6tims / direction

    MNBF

    ≥20,000times

    MTTR

    ≤ 30min

    Mechanical specification

    Dimension

    300mm×160mm×130mm (L x W x H)

    Weight

    5kg
