    EO IR Imaging Gimbal For UAV With 2-axis Stabilised Platform And HD+IR Dual Sensor

    Ask Lasest Price
    Brand Name : Wuhan Joho
    Model Number : JHP107-M145A
    Certification : ISO, SGS
    Price : negotiable
    Supply Ability : 500pcs per year
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    EO IR Imaging Gimbal For UAV With 2-axis Stabilised Platform And HD+IR Dual Sensor

    Mininature Gyro Stabilised eo ir imaging systems Camera Gimbal for UAV
    JHP107-M145A is a small UAV gimbal adopting 2-axis stabilized platform with high accuracy.Built-in 10× continuous zooming 1080p HD day light camera and uncooled thermal camera with 35mm focal length.It is mainly used for UAV to search,observe and track the land or sea targets,which can satisfy the aerial photography,flight navigation,reconnaissance and other application demands.
    Features
    • HD+IR dual sensor for day and night surveillance
    • 2-axis (azimuth and elevation) gyro stabilization covers the whole surveillance area without dead corner
    • Wireless digital transmission
    • Standard communication interface
    • Small size,light weight,compact structure,high adaptability,low power consumption and great cost-efficiency

    Technical Specification


    DescriptionGyro-stabilized Multi-sensor
    PlatformTwo-axis
    Azimuth rangen×360°
    Elevation range-35°~+110°
    Max angle speed≥60°/s
    Max angular acceleration≥80°/s2
    Stabilization accuracy≤0.5mrad
    Angular accuracy±0.1°
    IR Camera
    DetectorVOx uncooled FPA
    Pixel640×512
    Spectrum7.5~13.5μm
    Focal length35mm
    Pixel size17μm
    Frame frequency25Hz
    Digital VideoSD-SDI interface
    Daylight Camera
    Resolution1920×1080
    Focal length4.9mm~49mm(10× optical zooming)
    FOV7°03'×4°~49°28'×7°28'
    Frame frequency30Hz
    Digital VideoHD-SDI interface
    External Interface
    VideoHD-SDI interface(Two-way)
    CommunicationRS232/RS422/RS485
    Control protocolPelco-D and extended protocol
    Power SupplyDC 12V
    Power consumption≤15W
    Physical
    Dimension≤Φ145mm×205mm
    Weight≤2.5kg
    InstallationBelow belly
    ColorWhite & black
